Spartan® RT-HD - Engineered Tough for Daily Mowing
Key Features
1 1/2" x 3" Tubular Welded Frame
Strong, heavy-duty welded frame built for durability and stability.
Front & Rear Radial Tires
Radial tires for improved traction and a smooth, stable ride on various surfaces.
TecsPak® Under Seat
Innovative TecsPak® under-seat technology for added comfort and support.
360-degree Seat Plate
Fully adjustable 360-degree rotating seat plate for personalized seating positions.
Full Beam LED Light Bar
High-intensity full beam LED light bar for exceptional visibility in low light.
Magnetic Pin Height Adjustment
Effortless, precise cutting height adjustment with a secure magnetic pin system.
Adjustable Steering Arms
Customizable steering arms for enhanced comfort and improved handling.
Folding ROPS
Foldable Roll-Over Protective Structure (ROPS) for safety and compact storage.
GT Trac Stabilization
GT Trac Stabilization system for superior traction on uneven terrain and smoother rides.
18,500 FPM Blade Tip Speed
Durable side deck trim designed to protect against debris and wear.
Protective Side Deck Trim
Heavy-duty upgraded spindles for added durability and precise cutting action.
Upgraded Spindles
Robust 7-gauge XTF deck for exceptional strength and superior cutting quality.
7-gauge XTF Deck
Easy-to-use foot-operated parking brake for quick, hands-free operation.
Foot Operated Parking Brake
Convenient 12V outlet for powering devices or charging electronics while on the go.
12V Outlet
Spacious cup holder to keep beverages secure and accessible during operation.
Large Cup Holder
Handy phone holder integrated into the console for easy access and storage.
Phone Holder in Console
Integrated phone holder for easy access and secure storage while working.
Storage Tray in Console
Practical storage tray in the console for small tools and personal items.
2" Receiver Hitch
Heavy-duty 2-inch receiver hitch for towing attachments and accessories.
Key Switch Panel
Secure key switch panel for easy ignition and reliable start-up.
Foot Operated Shock Assisted Deck Lift
Foot-operated deck lift with shock assistance for smooth, effortless adjustments.
Anti-Vibration Floor Mat
Anti-vibration floor mat to reduce fatigue and increase comfort during extended use.
Ultra Premium Dymetrol ® Adjustable 3" Travel Seat
Ultra-premium Dymetrol® seat with 3 inches of adjustable travel for personalized comfort.
Model Comparison
| Model | Deck Size | Engine | Horsepower | Transmission | Top Speed | Fuel Capacity |
|---|---|---|---|---|---|---|
| RZ-XD | 48" / 54" / 60" | Kawasaki FX730V 24 HP | 24 HP | Parker HTE Transaxles - 10cc Drive Motors | 9 MPH | 9.5 gal |
| RZ-XD Blackout | 54" / 60" | Kawasaki FX801V 25.5 HP | 25.5 HP | Parker HTE Transaxles - 10cc Drive Motors | 9 MPH | 9.5 gal |
| RT-HD | 54" / 61" / 72" | Vanguard EFI 993cc 37 HP / Kawasaki Vanguard EFI 993cc 37 HP / Kawasaki FX1000 35 HP | 35 / 37 HP | Parker HTJ Transaxles - 12cc Drive Motors | 11 MPH | 9.5 gal |
| SRT-XDe | 54" / 61" | Kawasaki FX801V 25.5 HP | 25.5 HP | Parker HTJ Transaxles - 12cc Drive Motors | 11 MPH | 9.5 gal |
| SRT-XD | 61" / 72" | Kawasaki FX1000 EFI 38.5 HP / Vanguard EFI 994cc w/OG 40 HP | 38.5 / 40 HP | Parker HTG Transaxles - 16cc Drive Motors | 13 MPH | 9.5 gal |
| KGZ-XD | 61" / 72" | Vanguard EFI 994cc w/OG 40 HP | 40 HP | Parker HTG Transaxles - 16cc Drive Motors | 15 MPH | 17 gal |
Available Accessories (Sold Separately)
No available accessories data found.
Offers and Financing
Best Rates for Qualified Buyers
Designed for top-tier credit customers who want the lowest rates on mowers and outdoor power equipment. Personal and commercial financing available with no early payoff penalties.
Prequalify
Fast Approval. Flexible Credit.
A strong fit for customers rebuilding or strengthening credit. Personal and commercial equipment loans with fast approvals and no prepayment penalties.
Prequalify
Equipment Without the Wait
Fast, simple approvals for entrepreneurs needing equipment quickly. Covers new and used outdoor power equipment with instant decisions up to $25,000.
Prequalify
Flexible Payments Made Simple
Ideal for mid to top-tier credit customers who want payment flexibility. Revolving credit makes it easy to finance mowers, handheld equipment, and smaller purchases.
View Details
Real Solutions for Real Credit
A strong option when traditional financing says no. Same-day approvals available for new and used mowers and equipment.
View Details
SPARTAN - Spring Mower Sales Event
Spring Mower Sales Event valid from April 1 – June 30, 2026. Credits are issued on qualified retail sales during the promotional period.
Learn MoreSpecification Highlights
Engine
Engine Name: 61" Vanguard EFI 993cc 37 HP, 72" Kawasaki Vanguard EFI 993cc 37 HP, 54" Kawasaki FX1000 35 HP, 61" Kawasaki FX1000 35 HP, 72" Kawasaki FX1000 35 HP
Horsepower: 35 HP / 37 HP
Fuel Capacity: 9.5 Gallons
Drive Line
Hydraulic Drive: Parker HTJ Transaxles - 12cc Drive Motors
Hydraulic Drive Torque: Continuous - 262 ft-lb | Max Torque - 406 ft-lb
Hydraulic Drive Maintenance: 1,000 Hours Between Oil Change
Front Tires: 13x6.5-R6 Radial
Drive Tires: 24x12-12 Radials
Wheel Type: Steel
Speed (F/R): Forward - Up to 11 mph | Reverse - Up to 5 mph
Features
Acreage: 4+
Seat: Full Suspension Seat with Adjustable TecsPak Elastomer supports and 360-degree Floating Seat Platform
Steering Levers: Soft-Touch Knobs to Adjust Forward and Back. Adjustable Up and Down
Control Panel LCD Display: Hour Meter - Engine Hours, Tachometer
Control Panel LED Warning Indicators: N/A
Ignition: Key Switch
Auxiliary Power: 12v Outlet
Storage: Phone Holder, Cup Holder, and Deep Storage Tray
Hitch: 2" Rear Receiver
LED Light Bar: Full Beam
Cutting Deck
Deck Size: 61"
Deck Depth: 6" Deep, Reinforced 7 Gauge Full-Floating Deck
Deck Lift: Foot Operated with Shock Assist
Deck Adjustment: Magnetic Pin Height Adjustment
Cut Height: 1.5" to 4.75" with 14 Cut Heights
Blade Spindles: Cast Aluminum, No Maintenance/Sealed Bearings
Parking Brake: Foot Operated
Frame: 1.5" by 3" Powder Coated Fusion-Bonded Solid Steel Bridge Frame
Measurements
Width: 61” Deck - 62.5” Wide
Weight: 1143 lbs
Length: 84”
Height: 75" with ROPS Up | 54" with Folding ROPS Down
Warranty
Engine Warranty: 3 Year
Leading Deck Edge Warranty: 3 Year
Hydraulic Drive Warranty: 3 Year / 1500 Hour
Control Panel Warranty: N/A
Product Warranty: 3 Year / 500 Hour
Battery Warranty: 6 Months
Belt Warranty: 90 Days
