Hustler Raptor - Rugged Build, Year Round Reliability
Key Features
Welded Steel Deckz
11 ga. welded fabricated steel deck.
Wider Stance
Additional operator platform width provides ample room and comfort for the operator.
SmoothTrak Steering
Precision control designed to help trim and maneuver easily around obstacles.
Bolstered Seat
Helps provide a comfortable ride with
Rubber Floor Mat
Helps provide comfort by minimizing vibration on the operator's feet. Standard on all Raptor models.
Fabricated Frame
Continuous one-piece 1½ inch by 3 inch welded tubular frame.
Foot-Operated Deck Lift
Easily adjust the deck height between 1.5” - 4.5”.
Easy to Service
Flip-up seat pan, removable floor pan, vented pulley covers.
Standard on all Dash XD models.
Powered by a V-Twin Kawasaki engine.
20" Drive Tires
Kawasaki® Power
Model Comparison
| Model | Ideal For | Deck Size | Engine | Horsepower | Transmission | Top Speed | Fuel Capacity |
|---|---|---|---|---|---|---|---|
| Dash XD | Up to 1 acres | 34" | Kawasaki® FR541 | 15 HP | Hydro-Gear® ZT-1800™ | Up to 6 MPH | 2 gal |
| Raptor X | Up to 3 acres | 42" / 54" | Kawasaki® FR600 / FR651 | 18 HP / 21.5 HP | Hydro-Gear ZT-2200 | Up to 7 MPH | 3.5 gal |
| Raptor XL | Up to 3 acres | 42" / 54" | Kawasaki® FR651 / FR691 | 21.5 HP / 23 HP | Hydro-Gear ZT-2200 | Up to 7 MPH | 3.5 gal |
| Raptor XD | Up to 5 acres | 48" / 54" / 60" | Kawasaki® FR651 / FR691 / FR730 | 21.5-24 HP | Tuff Torq TZ350 | Up to 7.5 MPH | 3.5 gal |
| Raptor XDX | Up to 5 acres | 48" / 54" / 60" | Kawasaki® FR651 / FR691 / FR730 | 21.5-24 HP | Hydro-Gear ZT-3100 | Up to 8 MPH | 3 gal |
Available Accessories (Sold Separately)
Offers and Financing
Best Rates for Qualified Buyers
Designed for top-tier credit customers who want the lowest rates on mowers and outdoor power equipment. Personal and commercial financing available with no early payoff penalties.
Prequalify
Fast Approval. Flexible Credit.
A strong fit for customers rebuilding or strengthening credit. Personal and commercial equipment loans with fast approvals and no prepayment penalties.
Prequalify
Equipment Without the Wait
Fast, simple approvals for entrepreneurs needing equipment quickly. Covers new and used outdoor power equipment with instant decisions up to $25,000.
Prequalify
Scale Your Operation
Commercial financing and leasing up to $250,000 for serious lawn and landscape operations. Fund entire equipment packages with structured terms built for business growth.
View Details
HUSTLER - Spring Sales Event
Spring Sales Event valid from April 15 – May 31, 2026. Discounts apply when products are sold at or below promotional MAP pricing.
Learn MoreSpecification Highlights
Key Features
Engine Manufacturer: Kawasaki FR651
Engine Horsepower: 54" : 21.5 | 42" : 18
Transmission: Hydro-Gear ZT-2200
Fuel Capacity: 3.5 gal.
Ground Speed (Fwd): Up to 7 mph
Cutting Width: 54" | 42"
Cutting Height: 1.5" to 4.5"
Front Tire: 11 X 6.5
Drive Tire: 54": 20 x 10-8 VersaTrack | 42":20 x 8-8 VersaTrack
Warranty: 3 Year/300 hour residential
Engine
Engine Manufacturer: Kawasaki FR651
Engine Horsepower: 54":21.5 | 42":18
Displacement: 54" : 726CC | 42" : 603cc
Cooling: Air Cooled
Engine Warranty: 3 Year Warranty
Drive System
Type: Dual Hydrostatic
Transmission: Hydro-Gear Zt-2200®
Engine Warranty: 3 Year Warranty
Fuel Capacity: 3.5 Gal.
Ground Speed (Fwd): Up To 7 Mph
Parking Brake: Integrated With Steering Levers
General
Front Tire (Inches): 11 X 6.5
Drive Tire (Inches): 54" : 20 X 10-8 VersaTrack | 42" : 20 X 8-8 VersaTrack
Weight (Lbs): 54" : 592/625 | 42" : 570
Height (Inches): 40.8
Length (Inches): 70.6
Width W/ Chute Up (Inches): 58.6
Tire-To-Tire Width (Inches): 46.5
Productivity (Acres Per Hour): 54" : 3.05 | 42" : 2.38
Dimensions
Warranty: 3 Year/300 Hour Residential
Warranty
atcher Style: 2-Bag
Powered / Non-Powered: Non-powered
Catcher Capacity: 5.4 bushel
Mower Length W/ Catcher: 91.4
Mower Width W/ Catcher: 54": 69.5 | 42" : 56.5
Dimensions w/ Catcher
